Four piller bering press machine

Four piller bering press machine Specification

Nominal Force
100 Tons

Power Source
Hydraulic with electric drive

Condition
New

Dimension (L*W*H)
1600 mm x 1100 mm x 2300 mm

Power(W)
11 kW

Voltage
380V / 415V, 3 Phase, 50 Hz

Motor
High-efficiency IE2/IE3 motor

PLC System
Available (Optional)

Solenoid Valve
Fitted

Pre-Fill Valve
Included

Proportional Valve
Available on request

Pressure Gauge
Provided, analog or digital (as per model)

Max Opening Distance
650 mm

Working Table Size
900 mm x 700 mm

Ram Stroke
250 mm

Main Cylinder Material
Alloy steel, finely honed

Application
Pressing, punching, forming, straightening, and assembling metal components

Oil Tank Capacity
250 Liters

Approach Speed
80 mm/sec

Return Speed
60 mm/sec

Hydraulic Fluid
ISO VG-68 or equivalent

Weight
Approx. 3500 kg

Safety Features
Two-hand operation, mechanical limit switches

Frame Type
C Frame, heavy-duty welded construction

Type of Control
Push button & foot switch

Four piller bering press machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
10 Days

About Four piller bering press machine

Ending Soon-take advantage of this spectacular Deal on our Gorgeous C Frame Hydraulic Press! Engineered with a lofty heavy-duty welded construction, this 100-ton press is designed for superior performance and safety. The robust C Frame structure offers exceptional accessibility for pressing, punching, forming, straightening, and assembling metal components. It comes equipped with an 11 kW high-efficiency IE2/IE3 motor, optional PLC system, and an array of safety features, including two-hand operation and limit switches. Add to Cart now and transform your production capabilities before this offer vanishes!

Versatility & Applications of C Frame Hydraulic Press

The C Frame Hydraulic Press finds its area of application in metalworking industries, excelling at pressing, punching, forming, straightening, and assembling metal components. Its robust frame and powerful operation make it ideal for automotive, fabrication, equipment manufacturing, and tool making. With easy access and reliable control, this press is perfect for both standard production lines and specialized tasks at manufacturing plants, workshops, and industrial sites.

Sample Policy & Main Export Markets

Our premium C Frame Hydraulic Press sample policy ensures that samples are available for evaluation before bulk procurement. Samples are securely packed and handed over to trusted Goods Transport partners, guaranteeing safe delivery to your site. Main export markets include Asia, Africa, and the Middle East, with distributor and service networks ready to assist. Experience peace of mind with our exceptional product quality and reliable after-sales support, tailored for global clients.

FAQ's of C Frame Hydraulic Press:

Q: How does the C Frame design benefit metalworking operations?

A: The C Frame design provides open access to the working area, allowing for easy handling of workpieces and efficient operation. Its sturdy, welded structure minimizes deflection, ensuring precise, repeatable results in pressing, punching, and forming tasks.

Q: What safety features are included in the C Frame Hydraulic Press?

A: This hydraulic press incorporates two-hand operation controls and mechanical limit switches to enhance operator safety and prevent accidental activation, making it suitable for rigorous industrial environments.

Q: Where can the C Frame Hydraulic Press be used effectively?

A: The press is ideal for use in automotive workshops, metal fabrication plants, and manufacturing facilities requiring pressing, straightening, assembly, or punching of metal components.

Q: What is the process for obtaining a sample of this hydraulic press?

A: Interested buyers can request a sample for evaluation. Once approved, the sample is packed and handed over to premium Goods Transport partners for secure delivery to your specified location.

Q: Which hydraulic fluid is recommended for this press?

A: The recommended hydraulic fluid is ISO VG-68 or its equivalent, ensuring optimal performance, lubrication, and long service life for all moving components.
